A06B-6087-H130

Power Supply Module

1. Module Type:
   • Servo Amplifier/Drive Unit (for AC servo motor control).
   • Designed for high-performance motion control in CNC or robotics systems.
2. Electrical Specifications:
   • Input Voltage:
     • 3-phase AC 200-240V (±10%, 50/60Hz).
   • Output Power:
     • ~7.5 kW (estimated based on similar “H”-suffix drives).
   • Rated Current:
     • Continuous: 30-40A (dependent on cooling and load conditions).
   • Control Method:
     • PWM (Pulse Width Modulation) with vector control for dynamic torque/speed regulation.
3. Motor Compatibility:
   • Optimized for Fanuc αi or βi-series high-power servo motors (e.g., A06B-xxxx-Hxxx motors).
   • Supports absolute/relative encoders for closed-loop feedback.
4. Physical Specifications:
   • Dimensions:
     • Approx. 300mm (W) × 200mm (H) × 120mm (D) (size may vary with heat dissipation design).
   • Weight: ~6-8 kg.
   • Cooling Method:
     • Forced air cooling (built-in fan) or liquid cooling (model-dependent).
5. Performance:
   • Control Resolution:
     • Sub-micron precision for CNC axis positioning.
   • Operating Temperature:
     • 0°C to +55°C (derating required above 45°C).
   • Protection Features:
     • Overcurrent, overvoltage, short-circuit, overtemperature, and phase-loss protection.
6. Communication Interface:
   • FSSB (Fanuc Serial Servo Bus) for seamless integration with Fanuc CNC controllers (e.g., Series 30i/31i/32i).
   • Digital I/O ports for external control signals (e.g., enable, fault feedback).
7. Certifications:
   • CE, UL, and ISO 13849-1 (functional safety compliance).
8. Application:
   • High-power CNC machines (e.g., machining centers, lathes), heavy-duty industrial robots, and precision automation systems.
