A06B-2015-B203

AC Servo Motor

1. • AC Servo Motor (high-performance industrial-grade motor).
   • Designed for precise motion control in CNC machines, robotics, or automated systems910.
2. Electrical Specifications:
   • Rated Voltage:
     • AC 200-240V (±10%, 50/60Hz) (common for Fanuc servo motors, similar to A06B-0075-B203)9.
   • Rated Torque:
     • Estimated 1.5 Nm (inferred from the “2015” model number, which may indicate torque or power class).
   • Maximum Speed:
     • ~6000 RPM (aligned with the A06B-2115-B203’s performance)10.
   • Encoder Type:
     • BiA-series incremental encoder (e.g., BiA 1000 for high-resolution feedback)10.
3. Mechanical Specifications:
   • Shaft Configuration:
     • Keyed shaft (ensures secure mechanical coupling, as seen in A06B-2115-B203)10.
   • Mounting Style:
     • Straight (ST) configuration for linear motion applications10.
   • Pole Count:
     • Likely 8 poles (similar to A06B-0075-B203)9.
4. Physical Specifications:
   • Dimensions:
     • Approx. 10.0 x 6.0 x 8.0 inches (similar to A06B-0075-B203)9.
   • Weight:
     • ~17-20 lbs (7.7-9.1 kg) (based on comparable models)910.
5. Performance:
   • Precision:
     • Sub-micron-level positioning accuracy (typical for Fanuc servo motors).
   • Cooling Method:
     • Natural convection or forced air cooling (standard for compact servo motors).
6. Compatibility:
   • System Integration:
     • Compatible with Fanuc CNC controllers (e.g., Series 0i, 30i) and servo drives (e.g., A06B-6073/H series)11.
   • Motor Series:
     • Likely part of the Fanuc αi or βi series (common for industrial automation)10.
7. Certifications:
   • CE, UL, and RoHS compliance (standard for industrial Fanuc products)910.
8. Application:
   • CNC machining centers, robotic arms, packaging machinery, and other high-precision automation systems
